STEEL WIRE ROPE 19X7+IWS |
حبال صلب و سلك واير مجدول جدلة فرنساوي قلب صلب 7*19 |
|
وفر شركة عبد السلام ابراهيم الزكي سلك واير و حبال صلب قلب صلب ذات تصنيف 7*19 (جدله فرنساوى) و يتكون هذا النوع من الحبال الصلب من 19 جدلات من الواير المجدول تتكون الواحده منها من 7 من اسلاك الواير المجدول يتميز هذا التصنيف من الوايرات الصلب بمقاومة دوران الأحمال
Rotation Resistant 19X7 Non-Rotating Wire Rope With Steel Core
Steel Wire Rope 19X7 class wire rope offers excellent rotation-resistance by laying 6 strands around a core in one direction and 12 strands around the first set of strands in the opposite direction. When under tension, the opposing rotational forces work in tandem to create excellent rotation resistanc. Applications
|
19X7+IWS With Steel Core Wire Rope
|
لمزيد من الامان والسلامة هذا النوع من منتجات الحبال الصلب يجري صناعتها وفقا لتوصيات المواصفات القياسية العالمية
For More Safety And Security This Type Of Steel Wire Products Are Manufactured According To The Recommendations Of International Standards : DIN 3069, DIN EN 12385-4, ISO 2408
STEEL WIRE ROPE 19X7+IWS Specifications
| Steel Wire Rope 19X7+IWS-01.pdf |
| Steel Wire Rope 19X7+IWS-02.pdf |
#ELZEKKIWIRE Rotation Resistant 19X7 Wire Rope With Steel Core
The very basic rotation resistant wire rope, extensively used as hoisting rope for various cranes (provision cranes, hose cranes etc). Also used as life-boat falls. Less flexible compared to 35(W)x7 but more abrasion resistant. Its construction is according to EN 12385 standard.
The 19X7 class wire rope is recommended for hoisting unguided loads with a single part line. It is not intended to be used with a swivel.
The 19X7 class wire rope offers excellent rotation-resistance by laying 6 strands around a core in one direction and 12 strands around the first set of strands in the opposite direction. When under tension, the opposing rotational forces work in tandem to create excellent rotation resistance.
This wire rope construction is available in ungalvanised finish . The construction 19X7. For further flexibility and other performance characteristics we also supply , 35X7. Depending upon your requirement for higher breaking load or better wear characteristics, these wire ropes are available in different finishes and lubrications.
The very basic rotation resistant wire rope, extensively used as hoisting rope for various cranes (provision cranes, hose cranes etc). Also used as life-boat falls. Less flexible compared to 35(W)x7 but more abrasion resistant. Its construction is according to EN 12385 standard.
The 19X7 class wire rope is recommended for hoisting unguided loads with a single part line. It is not intended to be used with a swivel.
The 19X7 class wire rope offers excellent rotation-resistance by laying 6 strands around a core in one direction and 12 strands around the first set of strands in the opposite direction. When under tension, the opposing rotational forces work in tandem to create excellent rotation resistance.
This wire rope construction is available in ungalvanised finish . The construction 19X7. For further flexibility and other performance characteristics we also supply , 35X7. Depending upon your requirement for higher breaking load or better wear characteristics, these wire ropes are available in different finishes and lubrications.
